THE FEATURE HIGHLIGHTS OF DY18

THE GUIDE DIAGRAM

 Applications:

1. Test for continuity

2. Test for polarity of a voltage

3. Check switches, relays and the on-off of diodes, fuses and circuits

4. Test for polarity of electric cables and plugs

5. Track and locate short circuits

6. Test for bad ground contacts

Specification:

Operation voltage: 6-24V DC

Cable length: about 4m

Overload protection: 10A (When the current exceeds 10A, this item will disconnect the current automatically.)

Weight: about 200g

Do's and don'ts:

 1. Do not use the item around explosive gas, vapor, or dust. When the power switch is pressed (or rocked), battery current is conducted directly to the tip which may cause sparks when contacting ground or certain

circuits.

2. The unit is not to be used with 110/220V house current, it is only use for DC 6~24V systems.

3. Do not use on AC voltage.

4. After you finishing checking vehicle, correctly restored all the connection-s which you disconnected.

5. Always follow the instructions and procedures indicated in the vehicle's service manual before attempting to disconnect any part or subsystem of the electrical circuit.

6. Never touch any dangerous part of the vehicle with your hand for safety. Don't touch any live conductor with hand or skin.

7. Don't use it if it is damaged.

8. Some components of vehicle work on low voltage, they cannot withstand the voltage allied by the item. To avoid damage for these components, don't use the item to apply voltage directly or indirectly.

9. Before driving, please always make sure that the vehicle is safe and reliable.

10. Don't use this item when driving.

PRODUCT DETAIL PRESENTATION

PRODUCT SPECIFICATIONS
