CWZ-102 type stern shaft speed direction measuring device
Inhouse product
| Emal və fərdiləşdirmə | Bəli |
| Brend | Digər |
| Model | CWZ-102 |
| Növ | Elektron taxometr |
| Ölçü diapazonu | Measuring range: 30~soil 999 rpm |
| Ölçmə dəqiqliyi | -- |
| Ayırdetmə | -- |
| Ölçü | -- |
| Enerji təchizatı | -- |
| Məhsul № | -- |
| Sərhədlərarası ixrac təchizatı olub-olmaması | No |
| Supply voltage: | (1) power supply voltage: dc24v plus or minus 20% (or ac220v) |
| Working environment: | Working environment: ambient temperature -20c~+60c, relative temperature ≤98% |
CWZ-102艉轴转速方向测量装置用于测量船舶艉轴（中轴）的转速和反方向，可进行多路指示。 该装置由微电脑控制，完全数字化。 检测能力强，可靠性好。 采用双大屏幕数码管显示，度数正确、直观、稳定，前进变绿，后退变红，停车时变橙。 该装置为非接触式磁感应测量，灵敏度高，感应距离大，小磁铁感应测速，省去沉重的测速齿轮板，安装方便。 可连接 2 至 10 个双向指针转速表和 5 个数字艉轴转速表。
CWZ-102 Stern Shaft Speed Direction Measuring Device is used to measure the speed and reverse direction of the ship's stern shaft (middle shaft), which can be used for multi-channel indication. The device is controlled by a micro- computer and is fully digitized. It has strong detection ability and good reliability. Using double large screen digital tube display, the degree is correct, intuitive, stable, forward turn green, backward turn red, when parking orange. The device is non-contact magnetic induction measurement, high sensitivity, large induction distance, small magnet induction speed measurement, eliminating heavy speed measuring gear plate, easy installation. Two to ten bi-directional pointer tachometers and five digital stern shaft tachometers can be attached.
