CWZ-101 W-type stern shaft speed direction measuring device
Inhouse product
| Emal və fərdiləşdirmə | No |
| Brend | Digər |
| Model | CWZ-101 |
| Növ | Elektron taxometr |
| Ölçü diapazonu | Measuring range: 0 soil 600 rpm (0 soil 200, 0+250, 0+300, 0 soil 400, 0 soil 500, etc. are available |
| Ölçmə dəqiqliyi | -- |
| Ayırdetmə | -- |
| Ölçü | -- |
| Enerji təchizatı | Output Voltage: 0 soil 10V |
| Məhsul № | -- |
| Sərhədlərarası ixrac təchizatı olub-olmaması | No |
| Working environment: | Environmental temperature-20C-+60C, relative temperature≤98% |
| Power supply voltage: | Dc24v±20% (or ac220v) |
1.产品用途与特点
CWZ- 101W型艉轴转速方向测量装置，
适用于船舶艉轴(中间轴)转速测量和倒顺
转检测，可作多路指示。本产品简单可靠，
安装方便，电路设计新颖，具有艉轴倒顺
转自动检测功能，装置本身带有数字显示，.
可外接双向指针转速表2~10只。结构紧凑、
性能优良、使用寿命长，可靠性高。配套
转速表型号: 45C3-V. ZZ3-4、 F96-DC、
ZZ3- 1等。还可供VDR信号。
Usage and Characteristics
CWZ-101W Stern Shaft Speed Direction Measuring
Device is suitable for measuring and reversing the
speed of the ship's stern shaft (middle shaft), and can
be used for multi-channel indication. This product is
simple and reliable, with novel circuit design, automatic monitoring function of stern shaft inversion
and rotation. The device itself has digital display and
can be connected with 2-10 bi-directional pointer
tachometers. It has compact structure, excellent
performance, long service life and high reliability. Type of matching tachometer: 45C3-V, ZZ3-4, F96-DC, ZZ3-1, etc. It can also provide VDR signal
